Secure clamp (D) to upper two holes with
bolts (L) using 4mm Allen wrench (O) for
desks with a thickness of 10-55mm.
Secure clamp (D) to lower two holes with
bolts (L) using 4mm Allen wrench (O) for
desks with a thickness of 50-85mm.
Attach base support cover (E)to clamp base support (C). Tighten the clamp to the
desktop using the plastic knob.
L
O
10-55mm
50-85mm
L
O
E
To Next Page
