STEP 1 (Continued)
OPTION B: Grommet Base Installation
Slide long screw (F) through the top of the grommet base support (G) and install on base of
monitor stand with bolts (M) using 4mm Allen wrench (O). Apply pads (N) to bottom of base.
Position stand on desk with long screw through hole, and secure by using the support plate (H)
and washer (J) on underside of the mounting surface, tighten the nut (I) with wrench (Q).
A
G
M
O
F
N
Q
H
J
I
