Before operating the Elgin Pelican P, be certain that
you have read and understand all safety and opera-
tion information. If you have any questions, contact
your supervisor before proceeding.
INSTRUMENTS & CONTROLS
The numbers below refer to those indicated on
Figures O-1 and O-2.
1. Parking Brake On indicator - Indicates that
the parking brake is applied.
2. Restricted Air Filter indicator - Indicates
that the engine air filter is clogged and in need of
service.
3. Restricted Hyd. Filter indicator - Indicates
that one of the return filters at the hydraulic fluid
reservoir is clogged and in need of service.
4. Restricted Drive Filter indicator - Indicates
that the hydraulic fluid filter for the hydrostatic
drive is clogged and in need of service.
5. Low Eng. Oil Press. indicator (optional) -
Indicates that the pressure of lubricating oil in the
engine is too low for safe operation.
6. High Coolant Temp. indicator (optional) -
Indicates that the temperature of the engine
coolant is too high for safe operation.
7. Low Coolant Level indicator (optional) -
Indicates that the level of engine coolant is too low
for safe operation.
8. Low Hydraulic Oil Level indicator (optional)
- Indicates that the level of fluid in the hydraulic
system is too low for efficient operation.
9. Low/No Spray Water indicator (optional) -
Indicates that the supply in the water tank has
been nearly or completely used up.
O-1
OPERATION
OPERATION
