Eliminator Lighting MEGA FLAT HEX PAK - System Menu Options; DMX and SEcd Modes; Dimmer, Sound, and Auto Run Modes

11
SYSTEM MENU
MODE SET UP UP/DOWN DESCRIPTION
DMX Mode
Address
d001 ~ d512
Set DMX starting address
Channels
Ch06
Select DMX channel mode
Ch07
Ch08
Ch11
Ch12
No DMX Mode
blAc
When DMX signal is lost or interrupted,
unit switches all LEDs off
LASt
When DMX signal is lost or interrupted,
unit holds last state before signal was
lost
ProG
When DMX signal is lost or interrupted,
unit will run internal program
nAnU
When DMX signal is lost or interrupted,
the unit will default to manual setting
Delay Mode
dr-0 ~ dr-4
Select delay mode
SEcd Mode SEcd Mode
SEcd
Set unit to secondary mode
Dimmer Mode
Red dimmer
r000 ~ r255
Adjust red color intensity
Green dimmer
G000 ~ G255
Adjust green color intensity
Blue dimmer
b000 ~ b255
Adjust blue color intensity
White dimmer
U000 ~ U255
Adjust white color intensity
Amber dimmer
A000 ~ A255
Adjust amber color intensity
UV dimmer
u000 ~ u255
Adjust UV intensity
Flash
FS00 ~ FS15
Adjust ash speed; 00 is off, 01 is slow-
est, 15 is fastest
Sound Mode
Mode select
So01 ~ So16
Select from 16 built in sound modes
Sensitivity select
SJ-1 ~ SJ-8
Adjust sound sensitivity; 1 is lowest level
and 8 is highest level
Auto Run
Mode
Color Fade Mode
AF01 ~ AF16
Select from 16 color fade modes
Color Change Mode
AJ01 ~ AJ16
Select from 16 color change modes
Color Fade & Color
Change
A-JF
Color fade and color changes modes run
in a continuous cycle
Speed Set
SP01 ~ SP16
Adjust speed of cycle
Static Color
Select Mode
Color Select
CL00 ~ CL63
Select from the built-in static colors
Flash
FS00 ~ FS15
Adjust ash speed; FS00 is off, FS01 is
slowest, FS15 is fastest
Other Mode
Display on/off
don
Display screen always stays on
doff
Display screen off
IR Remote Function
on/off
Iron
IR remote function on
Irof
IR remote function off
Display normal/
inverse
Stnd
Display screen standard orientation
rEv
Display screen inverted orientation
Initialization mode
dEFA
Restore unit to factory settings
