Elinchrom ELC PRO HD 500 User Manual

OPERATION MANUAL
GEBRAUCHSANLEITUNG
MANUEL D’UTILISATION
MANUAL DE FUNCIONAMIENTO
MANUALE D’USO
GEBRUIKSAANWIJZING
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
Elinchrom LTD – ELC 500/1000 Pro HD – 08.2016 – (73017)
ELC 500/1000 Pro HD
is a registered trademark of ELINCHROM LTD, RENENS, SWITZERLAND
EN
DE
FR
IT
ES
NL
RU

Elinchrom ELC PRO HD 500 Specifications

General

Power Output	500 Ws
Color Temperature	5600 K
Battery	No
Sync Options	Sync cable, built-in receiver
Voltage	100-240 V AC
Compatibility	Elinchrom accessories
Modeling Light	300W Halogen (Proportional, Independent, VFC)
