Elinchrom ONE - Replacing the Flash Tube

Replacing the Flash Tube // 24091
1. Switch the unit off and remove the
charger.
2. Wait 45 min., whilst the internal
discharging is in progress. Flashtube
and internal reector dish can be hot!
3. To remove the glass dome, you
require a screwdriver.
Remove the four screws which
holds the glass dome with the
metal ring on the inner reector dish.
4. Never touch ashtubes, please use
gloves. Pull the ashtube carefully
out. HIGH VOLTAGE! Never touch
broken ashtubes or electrodes! In this
case remove the ashtube with an
isolated clamp!
5. Insert a new ashtube, please use
gloves.
6. Use only the original Elinchrom
ashtube for this unit, third party
ashtubes may damage the ash unit.
7. Please check that the trigger contact
fork rmly grips the ashtube.
8. Re-mount the glass dome with the
metal ring by using the 4x screws.
9. Ensure that all parts are in place and test the unit.
26 — ELINCHROM ONE User manual
