Elipson Chroma - IV. SETUP AND INSTALLATION; INITIAL PREPARATION

27
IV. SETUP
1. PREPARATION
During transport, the removable lid and the various elements of the turntable are secured
by foam wedges.
• Carefully remove the protective foams of the plate (1 & 2), the tonearm (3), and the counter
weight.
(4). Then gently remove the protective foam of the motor pulley (5), and the foam wedge
located under the pulley (6).
• Carefully remove the plate (pay attention to its weight) in order to remove the protective
foam of the chassis. Then reposition the plate back on its axis.
• Position the lid above the plate, and adjust the two hinges in the appropriate rooms.
Carefully check the orientation of the hinges and the proper t of the lid on the plate.
Press rmly to ensure good holding of the lid.
5
2
6
1
4
3
