Pre-installation
1. Carefully unpack the screen.
2. Always handle the screen in a leveled position on a clean surface.
INSTALLATION
Flush Wall Mounting
1. Mark the location of where the screen is to be installed for the pre-drilled hole.
2. After marking the area and drilling the hole, insert the proper screw into the drilled hole and leave
about 1/8” of an inch from the wall to mount the screen.
3. Mount your screen from the keyhole located on back of screen’s left and right end cap.
Ceiling Mounting
(additional hardware required)
Optional installation using a chain to hang the screen from the ceiling.
1. You can also hang the screen on a ceiling by using a chain (not included) and hang it by the two loops
(models 71-120) located on each end of the case or by the end cap’s ears (models 135-170).
Back of end cap
Front view
Side view
