ASSEMBLY STEPS
1. Attach the Front Stabilizers (2) and the Rear Stabilizer (3) to the Main Body (1),
Using 4 M10X75mm Round Head Bolts(23).
2. Take the Front Post (4) and join the Middle Computer Wire (26) with Lower Computer
Wire (28). Release the Tension Knob (34) from the Front Post (4) and connect the
Upper Tension Cable (25) to the Lower Tension Cable (27). (* Please read next note*).
Tighten with3 sets of M8 X 15mm Bolts (17) and 16 Curve Washers (16).
