Elite Pool Cleaner - Page 5

5
Step 3
Step 6
Assemble sufficient lengths of
hoses to cover the distance from
weir to furthest point away from
the weir, plus one extra length of
hose (fig 7)
Remove the air from the hoses
by pushing the hoses vertically
into the pool
Install the Elite Pool Cleaner
Weir Valve in the weir / skimmer
box inlet and attach the pool
hoses (please refer to page 3)
Switch on your filtration unit
1.
2.
3.
4.
Step 4
Return
nozzle
Weir/Skimmer box
Pre-installation Check list
(Fig. 7)
Step 5 - Australia Only
Remove bump strip
Align and insert one side of the
deflector assembly clasp (fig 3)
with slot on main body selecting
required position (fig 4)
“Click” other side of deflector
assembly clasp into corre-
sponding slot on the other side
of the main body (fig 5)
Replace bump strip and feed
through deflector “Spokes” for
correct alignment (fig 6)
1.
2.
3.
4.
(Fig. 4)
(Fig. 5)
(Fig. 6)
(Fig. 3)
Australia Only
