Arm and
Wall Plate
Hardware Included
01
x1
02
x1
Monitor Plate
This product contains
small items that could be a choking hazard if
swallowed. Before starting assembly, verify
all parts are included and undamaged. If
any parts are missing or damaged, do not
return the damaged item to your dealer;
please contact our customer service team.
Never use damaged parts!
NOTE: Not all parts and hardware included
will be used.
WARNING:
Philips Screws
M6 x 15mm
M6 x 30mm
Philips Screws
M4 x 12mm
M4 x 30mm
Washers
Ø6mm
M4-5-6
Spacers
L10mm
x4
x4
x4x4
Philips Screws
M8 x 25mm
M8 x 45mm
x4
x4
x8 x4
Spacers
L5mm
x8
TV Screws / Washers
M-A M-B M-C M-D M-E M-F
Hardware （Wall /Product)
5/16 x 2½ in
Lag Bolts
x3
x1
CA
Washers
Ø8mm
x3
B
Open end wrench
- 3 -
Extenders Nuts Bolts
3B
x2
3A
x2
4A
x8
4B
x8
To Next Page
