Page 298575C (Rev. B - 10/10)
LZS8WS*1B LZS8WS*2B LZS8WS*3B LZSDWS*1B
LZSTL8WS*1B LZSTLR8WS*1B LZSTL8WS*2B LZSTL8WS*3B LZSTLDWS*1B
17 7/8
454mm
15
381mm
7
178mm
7
178mm
O
7/16
11mm
MOUNTING HOLES
(6)
3 9/16
90mm
18 13/16
478mm
3 9/16
90mm
17 7/8
454mm
18 13/16
478mm
15
381mm
7
178mm
7
178mm
O
7/16
11mm
MOUNTING HOLES
(6)
Single Rough-In
Fig. 1
Two -Level Rough-In
Fig. 2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Elkay EZH2O LZS8WS 1B Series and is the answer not in the manual?

Elkay EZH2O LZS8WS 1B Series Specifications

General IconGeneral
Installation TypeWall Mounted
Cooling Capacity8.0 GPH
FilteredYes
Bottle Filling StationYes
ADA CompliantYes
MaterialStainless Steel
RefrigerantR134a
BrandElkay
ModelLZS8WS
Power115V
ActivationSensor
CategoryWater Dispenser
Cooling Capacity (Temperature)50°F
Voltage115V
Power Consumption (Cooling)370W
Water Pressure Requirement20-105 psi
Product TypeBottle filling station with water cooler
Series1B
Mounting StyleWall-mounted
FinishStainless Steel
TypeWater Cooler
Heating CapacityNo
Filter TypeNSF certified filter
Water Connection3/8" O.D. Tubing
CertificationsNSF/ANSI 61, NSF/ANSI 372
