Ellis 90H - Mitre Head Locking Handle; Idler Wheel and Bearing Assembly; Bearing Carrier Assembly; Drive Wheel With Vulcanized Rubber

Description
5367 5740 5775 Drive Wheel With Rubber
Page 4
Item Part
No. No. Description
1 4966 Mitre Head Locking Handle
2 4311 Flat Washer
Press center button to reset ratchet in Handle
Mitre Head Locking Handle
ALL MODEL SAWS
Part Number For Models
1440
1500
1600
1800
2000
3000
4000
90H
900
1000
1100
1200
Description
5365 5788 5849 Idler Wheel & Bearing Assy.
Idler Wheel and Bearing Assy.
With Vulcanized Rubber
Part Number For Models
1440
1500
1600
1800
2000
3000
4000
90H
900
1000
1100
1200
Drive Wheel With
Vulcanized Rubber
Part Number For Models
1100
1200
1500
1600
1800
2000
3000
4000
90H
1000
Item
No. Description
1 4500 4510 4514 Carrier Guide, 4 Reqd.
2 4499 4522 4522 Thrust Ball Bearing, 2 Reqd.
Bearing Carrier Assembly
1
2
