AM852 Veterinary Anaesthesia machine User’ Manual
11
2.4Control Evaporator
Please refer to the evaporator operation manual to find the more details .
1 .drug-adding knob 2.lock knob 3. concentration panel
4. viewing window 5.drug-releasing port
Figure 2-5 Control Evaporator
Items Remarks
1 Drug-adding knob Anticlockwise rotate screw cap to unload it, and the drug
can be put in, clockwise rotate screw cap to airproof.
2 Lock knob Press this button, and rotate concentration control switch
to set anaesthetic concentration.
5 Drug-releasing port You could see the Drug-releasing knob inside the evaporator
when you rotate the drug-adding knob to unload it. Unload
the drug-releasing knob, and release the drug.
