Elma Modulgrav - Technical Specifications

Quality from Tradition; Technology of Tomorrow
mbC:\DB-pdf\BedAnl\Modulgrav\-GB-300102.doc 5
4. Technical Specifications
Mechanical Data:
Clampable rings:
Inside diameter 13-20mm
Weight: 10kg
Widths of rings: 2-7mm Color: blue, grey
silver
Type height with
20mm model: (setting range)
0.8 to 6.5 mm
Type height with
12mm model: (setting range)
0.5 to 3.9 mm
Force of the diamond:
Lower case position
Medium case position
Upper case position
12N corresp. 1.2kg
14N corresp. 1.4kg
16N corresp. 1.6kg
Receiving diameter for diamond:
Receiving diameter for engraving miller:
∅ 2.5 mm
∅ 3.3 mm
.
Lift setting, course:
Lift setting, fine:
Diamond holder
108 mm
11 mm
Distance between table and
top diamond position:
175 mm
Distance between short clamping device
and top diamond position:
115 mm
Distance between long clamping device
and top diamond position:
85 mm
Dimensions:
(depth x width x height)
250 x 350 x 600
