ZERO POSITION OF ZIGZAG STITCH (for models 2005and 2007)
When the machine is set with zigzag lever at “0” and the pattern selector
dial at “ 1 “, the needle bar should not swing.
1 Set the pattern selector dial at “ 1 “ and the zigzag lever at “0”.
2 Remove the front panel (see page 6).
3 Turn the fly wheel toward you with your hand so that the cam follower B
comes on the bottom of zigzag cam C.
4 Vibrate the arms D in the direction of arrows as shown below.
5 Turn the screw E to make sure that the needle bar does not swing.
6 Attach the front panel.
