User Manual: Interactive Digital Signage
SW602296 Rev A, Page 26 of 39
Temperature Control
The IDS monitor contain a temperature sensor that provides the user with real-time
temperature readings. This reading can be found on the OSD menu by opening the OSD menu:
Information ► System Temperature. If the monitor senses temperatures higher than the
operating range, the monitor will go into “Thermal Protection Mode.” This mode allows the
monitor to remain operational during brief periods of use outside of its operating range.
In Thermal Protection Mode, the monitor will reduce the backlight brightness to bring the
internal temperature back within operating range. While in this mode, brightness cannot be
increased beyond the set value. If the internal temperature decreases below the Thermal
Protection Mode temperature for at least five minutes, normal operation is resumed. The OSD
temperature at which the monitor will enter the Thermal Protection Mode is in the table below.
When the Thermal Protection Mode is enabled, the following icon will appear in the Main Menu.
This will indicate that the Thermal Protection Mode is active.
Icon showing that Thermal Protection Mode is active
The user will be prompted to shut off the monitor within sixty seconds if the temperature
continues to rise after Thermal Protection Mode Step 2 has been enabled. If the system is not
manually turned off in sixty seconds, the touchmonitor will automatically turn off to prevent
permanent damage to the monitor. The table below shows the Auto Shut Off temperature.
Monitor
Orientation
Thermal Protection
Mode (°C) Step 1
Thermal Protection
Mode (°C) Step 2
Auto Shut Off
Temperature (°C)
ET3202L
Portrait
58 60 65 Landscape
Tabletop
ET4202L
Portrait 57 59 64
Landscape 51 53 58
Tabletop 50 52 57
ET4602L
Portrait 60 62 67
Landscape 58 60 65
Tabletop 62 64 69
