User Manual: Interactive Digital Signage
SW602296 Rev D, Page 8 of 34
Chapter 4: Mounting
Note: For your health and safety, it is strongly recommended that at
least two people handle, lift, or move these touchmonitors.
Note: Do NOT lay the display face-down as this can cause damage to
the monitor.
General Mounting Information
The following three mounting orientations are supported: landscape, portrait and table-top
mode.
Portrait Mode
When rotating the monitor to portrait mode, ensure that the Elo logo appears in the same
location as the pictures below.
