COMPONENT CHECKLIST
Before commencing installation check that all the following components have been sup-
plied with your Elson heater.
• Wall mounting bracket
• No.12 x 2” screws (2 off)
• No.8 x 1” screw (1 off)
• No.12 x 2” wall plug (2 off)
• No.8 x 1” wall plug (1 off)
• 15mm x 15mm straight push-fi t connector (fi tted)
• 15mm x 15mm 90 ° elbow push fi t connector (fi tted)
CONNECTIONS
Inlet connection -15mm ext. diameter
Water entry point - bottom and rear
Cable entry point - bottom and rear
ELECTRICAL
Model numbers
2.5kW - Elson EBW25 - 93 200 001
Electrical rating 2.3/2.5kW@230/240V
Nominal capacities Model EBW25 2.5 litres
Weight (full) Model EBW25 8.4kg
Rated pressure
Minimum supply pressure 0.05MPa (0.5 bar)
Maximum supply pressure 1.0MPa (10 bar)
Enclosure rated IP X2
Nominal commissioning times (minutes) to temperature ready
Model EBW25 16
STANDARDS AND APPROVALS
Complies with the requirement of EN 60335-2-35.
Nemko approved for electrical safety.
Complies with European Community Directives (CE).
Complies with UK water regulations, kiwa approved.
TECHNICAL SPECIFICATION
