BU-020
Operating Instructions for
Temperature Controller ELT-GP1
Revision 4
20.12.2018
Page 7 of 10
4.
Installation
4.1 Mounting
The housing is designed for wall mounting. Drill four holes, 4 mm, using the mounting template.
Attach housing with screws (not included). Glands are directed downwards.
4.2 Installation
Read chapter 3 ‘General Safety Instructions’ carefully prior to installation.
MORTAL DANGER!
Before connecting the mains lead, you must switch off all power to the complete control
cabinet!
First connect the ground conductor (green-yellow colour-coding) to the unit. Then connect the live
wires. Connect all necessary conductors (see chapter 2.4 ‘Terminal Connection Plan’).
Before putting the unit into operation, check that all contact screws at the terminal strips are
tight!
