Wiring diagram of additional electronic ringtone type 860A.
The electronic ringtone type 860A features a two or three-note ringtone connected between terminal 7 and terminal 8. The ringtone must be powered at
mains voltage. The doorbell rhithm follows the call push- button pressure.
A0 - Interphone type 6901, type 6901/D
A1 - Interphone series Petrarca type 6209
A2 - Interphone series 6600
type 6601/AU, 660C/AU, 6701/AU
type 6611/AU, 661C/AU, 6711/AU, type 6xxx/AUF
A3 - Interphone series 8870 type 8879
A4 - Interphone series tab type 7509, 7509/D
B0 - Monitor series Wide touch type 7311
B1 - Monitor series 7200 type 7211
B2 - Monitor series 6600
type 6621, 662C, 6721
type 6611, 661C, 6711, type 6xxx/F
B3 - Monitor series 6800
type 6801, type 68MV + 68M1
B4 - Monitor series Petrarca
type 6029/C + 6209 + 6145
type 6029 + 6209 + 6145
B5 - Monitor series Giotto type 6329, 6329/C
B6- Tab series door entry monitor type 7529, 7529/D
G - Additional power supply type 692G
X - Cable type 732H, 732I (Two twisted wires)
