K40515.R
NO/NC
C
MA
tramite Dip-switch o SaveProg)
CA/PA
S-
Uscita serratura elettrica 12 Vcc
S+
V-
V+
E+
Alimentazione locale da alimentatore
supplementare
E-
B1
Bus Due Fili Plus
B2
- contatto NC -> Jumper disinserito
• Morsettiera di collegamento
• Connection terminal block
• Bornier de connexion
• Anschlussklemmenleiste
• Caja de bornes de conexión
• Placa de terminais de ligação
NO/NC
C
MA
SaveProg)
CA/PA
S-
Electric lock output 12 VDC
S+
V-
Video input from external CCTV camera
V+
E+
Local power supply from additional power
supply unit
E-
B1
Due Fili Plus Bus
B2
- NC contact -> Jumper disarmed
NO/NF
C
MA
CA/PA
S-
Sortie gâche électrique 12 Vcc
S+
V-
Entrée vidéo via caméra CCTV extérieure
V+
E+
Alimentation locale supplémentaire
E-
B1
Bus Due Fili Plus
B2
- contact NF -> Cavalier désinséré
NO/NC
C
MA
oder SaveProg)
CA/PA
S-
Ausgang Elektroschloss 12 Vdc
S+
V-
Videoeingang Außen-
Videoüberwachungskamera
V+
E+
Lokale Versorgung über zusätzliches Netzteil
E-
B1
Bus Due Fili Plus
B2
