EM TEST UCS 500 Series
Operating Manual V 3.05 36 / 57
11. Voltage Dips as per IEC 61000-4-11
Dips Module for voltage Dips and short interruptions
11.1. Operation
The Surge menu offers different test routines for burst testing.
Power Fail IEC 61000-4-11 / 8 / 29
F1 : Quick Start
F2 : Standard test routines
F3 : User test routines
F4 : Magnetic field
F1 F2 F3 F4 F5 F6 F7
F1 Quick Start
Easy and fast online-operation of the equipment.
F2 Standard test routines
The operator can select between various preprogrammed test routines as required in different standards.
With the function key F4 the operator can select the standard routine for 50/60Hz magnetic field testing as per
IEC 61000-4-8.
F3 User test routines
The operator can select between various preprogrammed test routines which helps to accelerate testing and
which are very helpful especially during design.
F4 Magnetic Field
The operator can perform 50 / 60 Hz magnetic field test as per IEC / EN 61000-4-8.
