Specifications
www.emachines.com
9
Image cannot be adjusted full screen
Some video modes used by the monitor produce images that cannot be
adjusted all the way out to the bezel edge (the edge where the screen glass and
monitor casing meet).
This condition does not indicate that the monitor is defective.
Specifications
Specifications are subject to change without obligation or notification.
CRT
Flat 17-inch diagonal (16.0 inches viewable),
anti-reflective/anti-glare, 90° deflection, 0.25 mm dot pitch
Synchronization range
Horizontal frequency: 30-70 KHz
Vertical frequency: 50-160 Hz
Resolution
Maximum: 1280 × 1024 @ 60 Hz
Recommended: 800 × 600 @ 85 Hz
Dot rate
110 MHz
Power supply
Input voltage: AC 100-240 V @ 50/60 Hz
Max power consumption: 68W (at 1152 × 864 resolution)
Input signal
Video: Analog 0.7 Vp-p/75 Ohms
Sync: Separate sync, TTL level
Display analog input
Unlimited colors
Weight
Net: 40.7 lbs (18.5 kg)
Gross: 46.2 lbs (21.0 kg)
Dimensions (W×H×D)
15.98 × 16.02 × 16.42 inches
(406 × 407 × 417 mm)
Operating conditions
Temperature: 41°F to 104°F (5°C to 40°C)
Humidity: 20% ~ 80%
Storage conditions
Temperature: -4°F to 140°F (-20°C to 60°C)
Humidity: 10% ~ 90%
