EN 17CONTROLS AND INSTRUMENTS
– If the blades are engaged when safety conditions have not been complied
with, the engine shuts down and cannot be restarted (☛ 5.2).
– The “Blades engaged” condition is indicated by a pilot lamp (4.7.a).
– On disengaging the blades (position «A»), a brake is simultaneously activa-
ted which stops their rotation in few seconds.
For models with engagement by electromagnetic clutch
The pushbutton (4.9.2) is for engaging the blades by an electromagnetic clut-
ch:
«A» Released = Blades disengaged
«B» Pressed = Blades engaged
– If the blades are engaged when safety conditions have not been complied
with, the engine shuts down and cannot be restarted (☛ 5.2).
– The “Blades engaged” condition is indicated by a pilot lamp (4.7.a).
– On disengaging the blades (position «A»), a brake is simultaneously activa-
ted which stops their rotation in few seconds.
4.10 C
UTTING HEIGHT ADJUSTING LEVER
There are seven positions for this lever, shown as «1» to «7» on the label, which
correspond to various heights of between 3 and 9 cm.
– To go from one height to another, press the release button at the end of the
lever.
4.11 L
EVER FOR TIPPING THE GRASS-CATCHER
This lever, when pulled out from its hole, is to tip the grass-catcher to empty it and
reduce the effort required by the operator.
➤
