Powering EMC Celerra NX4 system
Power Up procedure for single SPS system
Note: Verify that the cabinet circuit breakers are in the ON position. If you are installing the NX4 into an
existing cabinet that contains other components, do not turn off the cabinet circuit breakers. Ensure that
the switch on SPS A is in the OFF position.
Connect the power cables as follows:
A yellow circle with a number indicates the power cable number.
1. Connect the power cables to the other DAEs through .
2. Connect the power supply A on the DPE to SPS A.
3. Connect power supply B on the DPE to the left PDP.
4. Connect SPS A power cable to the right PDP.
5. Turn on SPS A.
Wait for the storage array to power up. It can take 8 to 10 minutes to power up. The blinking orange
fault LED on the SPS will extinguish and the solid green power LED will turn on when the SPS is
powered up. The blinking green LED on each SP will become solid green LEDs when the SPs
have booted.
6. Connect the blade enclosure power cables to the PDP and .
The power LED on the blade enclosure will be lit when the blades have powered up.
7. Connect the power cable for the Control Station (CS).
If the system power LED does not light up, take the bezel off of the front of the CS and press the
power button.
10
9
1
8
11
12
13
14
#
