EMC Celerra NX4

21
For more information, refer to Celerra Tools on http://Powerlink.EMC.com
Cabling EMC Celerra NX4 system
Note: The blades in your system may have four port Ethernet copper or two port 10 GbE optical
and two port copper.
Power Up cabling procedure for single SPS system
CNS-001435
Blade 2
SP B
SP A
Control Station
Blade enclosure
SPS A
SPS B
SPS A power switch.
Power distribution panel
(PDP)
Disk processor
PDP
1
2
3
4
5
6
7
8
9
14
12
11
13
10
Disk processor
Optional disk-array enclosure
(DAE)
Optional DAE
Optional DAE
Optional DAE
