EMC Celerra NX4

22
For more information, refer to Celerra Tools on http://Powerlink.EMC.com
CONTROL STATION
MGMT
CS
A
CS
MGMT
B
Blade 2
DPE-AUX
SP B SP A
Blade 2
SPS B SPS A
FRU label
10/100
SP A
Blade 2
SP A
SPS A
2 AUX
3 AUX
0 Fibre 1 Fibre
2 AUX
3 AUX
0 Fibre 1 Fibre
2
3
FRU label
10/100
2
3
SP B 3 AUX
Blade 3 BE 1
Blade 3
Blade 2 BE 1
SP A 3 AUX
SP B 2 AUX
CS A
Blade 2 BE 0
SP B
Blade 3
SP A 2 AUX
Blade 3
Blade 3 BE 0
CS B
SPS B
SP B
If SPS B is installed in your system, connect the cable as shown.
CNS-001436
Cabling EMC Celerra NX4 system
Cabling diagram of the Celerra NX4 dual blade system with four port copper Ethernet.
