EMD EXP-103 - Page 22

22
ELECTRIC PARTS LIST FOR EXP-103
KEY NO
PART NO
DESCRIPTION
Q'TY
1Q2
P0305-010001200
POWER FUSE (IK60N2PC16A)
1
1Q2A
P0311-010002800
POWER SWITCH (ZH-HD-48-BY)
1
1Q4
P0307-010000400
POWER 24Vdc (DR-4524 24Vdc-2A)
1
2U2
73050215
73050218
PER-STRETCH INVERTER
INVERTER, ATV12H037M2, 220V
INVERTER, ATV12H037F1 1/2HP, 110V
1
1
2U8
73050216
P0315-010002100
TURNTABLE INVERTER
INVERTER, ATV12H075M2 1HP, 220V
INVERTER, ATV12H075F1 1HP, 110V
1
1
3U2
73050215
73050218
CARRIAGE INVERTER
INVERTER, ATV12H037M2, 220V
INVERTER, ATV12H037F1 1/2HP, 110V
1
1
3K7
P0306-010000400
POWER CONTACTOR (LC1D18BL,DC24V)
1
3S9
P0313-010000200
P0313-020000200
EMERENCY STOP, ZB2-BS54C
CONTACT, ZB2-BZ102CNCx1
1
1
3S9A
P0311-020000100
CARRIAGE BOX DOOR SWITCH ( TZ-93BPG)
1
4P1
P0309-010008200
MICROPRESSOR CARD
4S6
7150BW33
7150LD01/109A011
7150BW61
START BUTTON GREEN COVER, ZB2-BW33C
LAMP, DL1-LED241
CONTACT ,ZB2-BW061C
1
1
1
4S7
P0313-020002600
P0313-020000100
STOP BUTTON COVER ,ZB2-BA4C
CONTACT ,ZB2-BZ101CNOx1
1
A1
P0311-030000100
CARRIAGE BOX DOOR KEY (TZ93-K3)
1
B1
P1002-0006600
PANEL LABEL
1
B2
71610002
KNOB
1
