2. SPECIFICATION
2.1 SPEC. TABLE
Model
EXP-103
Turntable Speed
3 ~ 12 RPM
Turntable dia.
1500mm
Max wrapping height
2200mm
Pallet size
1050x1050mm
Max loading weight
2000kgs
Film stretch (%)
300% & 230% two step change by handle
(250% and 200% option)
Film tension
Adjustable – 3 STAGES SETTING
Carriage Unit speed
1.5 ~ 5m/min
Max. film spec.
∮ 250x500mm
Turntable height
71mm
Machine size
2458x1500x2559mm.
Standard option:
 1.65 & 1.80 meters dia. Turntable.
 2.6 & 3.0 meters wrapping height
 Top pressure plate driven by motor
 Ramp
 Mechanical roping
