6.1 SEAT PART LIST FOR EXP-103
KEY NO
PART NO
DESCRIPTION
Q'TY
1
P01-000081A
P01-000080A
TURNTABLE 1.5M
TURNTABLE 1.65M
1
1
2
P0311-060001200
LIMIT SWITCH VL-8108
1
3
P02-0050100
SENSOR PLATE
1
4
P0703-0001900
PULLEY
1
5
P1104-026205ZZ0
BEARING 6205ZZ(CWB)
1
6
P02-0050000
BEARING SEAT
1
7
P0902-0007300
P0902-0007400
BELT BX-140
BELT BX-144
1
1
8
P01-045120A
P01-044540A
TURNTABLE BASE 1.5M
TURNTABLE BASE 1.65M
1
1
9
P06-0003410
P02-0007000
SUPPORTING WHEEL
SUPPORTING WHEEL SHAFT
13
10
P01-0446100
COVER PLATE
1
11
P06-0028800
BELT BEARING PULLY SEAT
1
12
P02-0052400
BELT BEARING PULLY SHAFT
13
P06-0048200
MOTOR COVER
1
14
P01-0448300
MOTOR COVER SUPPORT FRAME
1
15
P01-0448400
MOTOR COVER SUPPORT FRAME
1
16
P0503-0008800
GEAR REDUCER MOTOR, 1HP
3-PH, 220V/380V
1
17
P01-0445500
MOTOR BASE PLATE
1
18
P0703-0002000
MOTOR BELT PULLY
1
19
P01-0066100
WASHER M8
1
