CARRIAGE PART LIST FOR EXP-103
KEY NO
PART NO
DESCRIPTION
Q'TY
1
P01-0449400
TENSION ADJUSTMENT COVER
1
2
P06-0049500
TENSION INDICATOR PLATE
1
3
P06-0049000
PLATE BRACKET
1
4
P01-0449300
CARRIAGE FRAME – COVER
1
5
P01-0448200
CARRIAGE FRAME – COVER BASE
1
6
P0501-0002800
GEAR REDUCER MOTOR 1/4HP,
3-PH, 220V/380V
1
7
P06-0049100
LIMIT PLATE
1
8
P06-0049200
SPROCKET 22T
1
9
P06-0049300
SPROCKET 25T
1
10
P06-0051000
SPROCKET 42T
1
11
P02-0002000
WASHER
1
12
P1104-026003ZZ0
BEARING 6003ZZ
2
13
P02-0291300
SPROCKET SHAFT
1
14
P02-029120A
BUSHING
1
15
P0901-0001700
CHAIN #35x36
1
16
P0702-0001000
CHAIN SPROCKET 17T
1
17
P01-0007200
ADJUSTING PLATE
2
18
P06-004980A
BUFFER RING
4
19
P01-0452700
CARRIAGE FRAME – TOP SEAT
1
20
P01-044920A
CARRIAGE FRAME – REAR PANEL
1
21
P0302-010001600
PROX SWITCH XS4-P18-AB110
1
22
P01-0448200
CARRIAGE FRAME – COVER BASE
1
23
P0311-060001100
LIMIT SWITCH VL-8108
2
24
P0304-010005600
CONNECTOR HOUSE 12P, 15A
1
25
P0302-020000200
PHOTO SENSOR A3R-2MX
1
26
P01-044590A
PHOTO SENSOR SEAT
1
27
P01-044890B
CARRIAGE FRAME – FRONT PANEL
1
28
P1113-0000400
KNOB M6*16L
1
29
P1202-0010400
PIN PUNCH SPRING
1
30
P02-0291800
PIN PUNCH JOINT
1
31
P01-0449500
PIN PUNCH LINKAGE
1
32
P02-0291000
PIN PUNCH SEAT
1
