Emerson 67C - Page 11

Bulletin 71.1:67C
11
STANDARD DIMENSIONS (INCLUDING CLOSING CAP) STANDARD DIMENSIONS (INCLUDING CLOSING CAP)
DIMENSIONS FOR PANEL MOUNT OPTION WITH HANDWHEEL
DIMENSIONS WITHOUT CLOSING CAP
Figure 10. Types 67CFS and 67CFSR Dimensions
4.56
(116)
3.00
(76)
1.48
(38)
4.93
(125)
1.14
(29)
4.00
(102)
OPTIONAL
GAUGE
VENT 1/4 NPT
1.43
(36)
2.56
(65)
0.62
(16)
CLOSING
CAP
0.69
(18)
1/4-INCH NPT INLET
CONNECTION
MOUNTING HOLES
FOR 5/16-INCH
DIAMETER BOLTS
2.25
(57)
2.87
(73)
INCHES
(mm)
1/4-INCH NPT
OUTLET
CONNECTIONS
1/4-INCH NPT
INLET CONNECTION
2.37
(60)
MAX
PANEL
0.12-0.25
(3-6,5)
2.65
(67)
4.13
(105)
5.00
(127)
MAXIMUM
INCHES
(mm)
MAXIMUM
