Emerson 67C - Page 10

Bulletin 71.1:67C
10
DIMENSIONS FOR PANEL MOUNT OPTION
WITH HAND WHEEL AND 1/4-INCH SPRING CASE VENT
DIMENSIONS FOR CLOSING CAP OPTION
WITH 1/4-INCH SPRING CASE VENT
INCHES
(mm)
Figure 8. Types 67CF and 67CFR Dimensions (continued)
2.56
(65)
1.43
(36)
2.87
(73)
2.25
(57)
0.69
(18)
MOUNTING HOLES
FOR 5/16-INCH
DIAMETER BOLTS
INLET CONNECTION
1/4-INCH NPT
OUTLET
CONNECTIONS
1/4-INCH NPT
4.69
(119)
CLOSING CAP
3.50
(89)
4.78
(121)
MAX
4.56
(116)
1.48
(38)
3.00
(76)
OPTIONAL GAUGE
SIDE OUTLET TAPPED
1/4-INCH NPT
1/4-INCH NPT VENT
0.72-INCH (1,8 mm)
SPRING CASE
PANEL BOSS
2.41
(61)
2.37
(60)
MAX
1.14
(29)
PANEL
0.12 TO 0.25
(3,0 TO 6,5)
B2700_A
Figure 9. Spacer Dimensions and Installation Schematic
SPACER
(FOR INSTALLING A 67CF SERIES
REGULATOR IN AN EXISTING
INSTALLATION IF THE MOUNTING
BOLTS ARE TOO LONG)
0.50
(12.7)
0.18
(4,57)
0.32
(8.12)
SPACER OUTER DIAMETER SPACER WIDTH AND
INNER DIAMETER
ID
OD
B2697_B
B2697_A
B2700_B
