Emerson 67C - Page 9

Bulletin 71.1:67C
9
Figure 6. Types 67CF and 67CFR Dimensions
DRAIN VALVE POSITIONS
DIMENSIONS
FOR GAUGE OPTION
STANDARD DIMENSIONS
B2699_A
3.50
(89)
3.50
(89)
4.56
(116)
1.48
(38)
3.00
(76)
2.56
(65)
0.62
(16)
2.87
(73)
2.25
(57)
0.69
(18)
OPTIONAL GAUGE
MOUNTING HOLES
FOR 5/16-INCH
DIAMETER BOLTS
SIDE OUTLET
1/4-INCH NPT
INLET CONNECTION
1/4-INCH NPT
INCHES
(mm)
OUTLET
CONNECTIONS
1/4-INCH NPT
B2699_B
VENT POSITIONS
INLET
OUTLET
GAUGE
VENT POSITION 3
VENT POSITION 4
VENT POSITION 1
(STANDARD)
VENT POSITION 2
B2699_C
DRAIN VALVE
POSITION 3
DRAIN VALVE
POSITION 2
DRAIN VALVE
POSITION 1
(STANDARD)
DRAIN VALVE
POSITION 4
INLET OUTLET
GAUGE
B2699_D
Figure 7. 67C Series Vent and Drain Valve Positions
