17
Hints For Better Reception
FM – Adjust the position and direction of the FM lead wire antenna until you find
the position and direction that provides the best reception.
AM – Adjust the direction of the AM loop antenna that you connected to the back
of the radio. If this does not provide sufficient improvement try removing the loop
from the antenna bracket and moving it further away from the radio cabinet (as far
as the wire will allow). You may also attach the loop to the wall with a thumbtack or
small nail through the “keyhole” on the antenna frame.
FM Wire Antenna
AM Loop Antenna
CKD2328_2330_B091103.p65 11/9/2003, 14:5117
