Remote Control (Model CKD2330 Only)
Model CKD2330 includes a credit card size 10-button remote control that allows
you to operate the CD player, control the volume, and switch the system ‘On’ and
‘Off’ from across the room. The remote control operates on one, button-style lithium
battery (Type CR2032 or equivalent), included. We have placed a clear plastic
spacer between the battery and the battery contact plate so that the battery will
remain fresh until you are ready to use the remote. Pull on the end of the spacer
tab to remove the spacer from the remote and activate the battery.
To use the remote control point the remote at the remote sensor on the front panel
of the radio and press the appropriate buttons on the remote. The effective operating
range of the remote is approximately 15 feet at an angle of no more than 15
degrees to the left or right of ‘dead center’.
When the remote control no longer works or the operation becomes intermittent it
is time to change the battery. Press downward on the locking tab and slide the
battery holder out of the remote as shown.
Remove the exhausted CR2032
battery from the holder, insert a fresh
battery into the holder with the “+” side
facing up, and slide the holder back
into the remote.
Spacer
