214
Epsilon Eb and EN Drives Reference Manual
NTM-207 and 212 Motors; Metric Face
Note
Mounting ears have clearance for 10mm across flats hex nut or 13mm O.D. washer.
NTM-207, 212 -CONS,TONS and LONS Mounting Dimensions
mm (inches)
A B C
D
Max
E F G
I
Max
J
Max
K
Min
L
Min
M
Min
207-CONS
140.96
(5.55)
65.18
(2.566)
7.49
(0.295)
60.012
(2.363)
2.54
(0.10)
5.80
(0.228)
75.0
(2.953)
23.51
(0.926)
10.999
(0.433)
13.0
(0.512)
3.97
(0.156)
2.0
(0.079)
207-TONS/
LONS
111.51
(4.39)
65.18
(2.566)
7.49
(0.295)
60.012
(2.363)
2.54
(0.10)
5.80
(0.228)
75.0
(2.953)
23.51
(0.926)
10.999
(0.433)
13.0
(0.512)
3.97
(0.156)
2.0
(0.079)
212-CONS
166.36
(6.55)
65.18
(2.566)
7.49
(0.295)
60.012
(2.363)
2.54
(0.10)
5.80
(0.228)
75.0
(2.953)
23.51
(0.926)
10.999
(0.433)
13.0
(0.512)
3.97
(0.156)
2.0
(0.079)
212-TONS/
LONS
136.91
(5.39)
65.18
(2.566)
7.49
(0.295)
60.012
(2.363)
2.54
(0.10)
5.80
(0.228)
75.0
(2.953)
23.51
(0.926)
10.999
(0.433)
13.0
(0.512)
3.97
(0.156)
2.0
(0.079)
1.780 [45.21]
MAX
1.925 [48.89]
MAX
A
ENCODER CONN: PT02E-16-23P
MATING CONN: PT06E-16-23S
(-CONS)
MOTOR CONN: PT02E-16-8P
MATING CONN: PT06E-16-8S
(-CONS)
F
DRILLED
THRU (4) EQUALLY
SPACED ON
G
