27
Operational Overview
Figure 15: External Shunt Wiring Diagram
Figure 16: EN
Bus Connections
Figure 17: Epsilon Bus Connections
Top View
-V
- Bus
Use 16 to 18 AW
G
stranded wir
e
+ Bus
J2
J3
+ Auxiliary Supply
- Auxiliary Supply
Two position header.
The mating ALPC-006 cables
is supplied with the
ALP Auxiliary Power Supply.
Side View
F
ront
Vi
ew
J1
