Emerson FB2200 Flow Computer Instruction Manual
D301784X012
March 2019
Introduction 9
1.9 FBxWifi™ Communications
The flow computer has an optional Wi-Fi
®
transceiver that enables you to connect via a laptop or
tablet from a distance. The distance supported varies depending on the laptop/tablet type and
environmental conditions but is typically 70 to 100 feet from the front of the flow computer and 40
to 60 feet from the side and rear of the flow computer.
This capability allows an operator to potentially remain outside the hazardous location and still
communicate with the flow computer. The operator's laptop must have Wi-Fi capability, line-of-
sight access to the HMI module, and must be loaded with FBxConnect configuration software.
Once connected, the operator can view process values, edit configuration parameters, and collect
logs.
Note
The FBxWifi electronics reside inside the HMI module. The HMI module must be awake to use
FBxWifi communications You can wake it up manually by holding a finger against the front cover
glass over the Hold to Wake button (the left-most button) for typically from five to ten seconds.
1.10 Software Tools
The FBxConnect configuration software provides a series of wizards that allow you to perform
configuration activities for the flow computer. You connect a PC running the FBxConnect
configuration software to the flow computer using one of the communication ports or through a
wireless connection. You can then:
▪
Set parameters within your application
▪
Configure I/O channels
▪
Specify the serial communication method for a port (RS-232 to RS-485) as needed
▪
View or collect audit trail information such as alarm, event, or historical logs
▪
Update system firmware
1.11 RoHS2 Compliance
Device without Integral MVS or SP Sensor:
RoHS (2) EU Directive 2011/65/EU
Device with Integral MVS or SP Sensor:
RoHS (2) EU Directive 2011/65/EU: This product may be considered out-of-scope when used for
the intended design purpose in a Large Scale Fixed Installation (LSFI).
Consult https://www.emerson.com/compliance for up-to-date product information.
1.12 Physical Security
The flow computer enclosure enables you padlock the door shut. The fiberglass enclosure supports
two padlocks (left in Figure 1-6); the aluminum enclosure supports one padlock (right in Figure 1-6).
