Figure 3
Note: Wire A-B
is
NOT required
when optional
timer is used
Time Delay Relay Specifications
Timer Opens1 Electrical cycleTimer Closes Greater than 5 seconds later
(.016 sec. with 60 HZ operation) power is restored or not
after power is removed
Typical Solid State Timer
(if used)
Fuse
Discharge Line
Thermostat (if used)
Compressor Contactor
Condenser Fan Contactor
(if used)
Other Protective
Devices (if used)
System Operating
Thermostat
230/240 VAC
C1
C
