BOTTOM VIEW
Install the leveling foot and the bottom hinge bracket on the new bottom side. Then tighten the
screws of the bottom hinge bracket.
Slot in the appliance door into the bottom hinge pin. Replace the upper hinge bracket on the new
side and check the fitting between the door/ hinge moving smoothly. Then tighten the screws of
upper hinge bracket. Replace the hinge cover and the right side screw cover.
Check that the door is aligned horizontally and vertically and that the seals are closed on all
sides before finally tightening the upper hinge. Re-adjust the leveling feet.
