14
UL Model No.: CF144 & CF152
Damp Part Numbers Wet Part Numbers
Key Model No. Model No. Model No. Model No. Model No. Model No. Model No. Model No.
No. Description CF144BS00 CF152BS00 CF144CRM00 CF152CRM00 CF144WW00 CF152WW00 CF144ORB00 CF152ORB00
1 Ceiling Mounting Plate 763987 763987 763987 763987 763987 763987 763987 763987
2 Ceiling Trim Ring 763989-BS 763989-BS 763989-CRM 763989-CRM 763989-WW 763989-WW 763989-ORB 763989-ORB
3 Ceiling Cover 763988-BS 763988-BS 763988-CRM 763988-CRM 763988-WW 763988-WW 763988-ORB 763988-ORB
4 Lower Housing 763992-BS 763992-BS 763992-CRM 763992-CRM 763992-WW 763992-WW 763992-ORB 763992-ORB
5 Light Kit Plate Assembly 764006 764006 764006 764006 764006 764006 764006 764006
6 Glass Shade 763994-OM 763994-OM 763994-OM 763994-OM 763994-OM 763994-OM 763994-OM 763994-OM
7 No Light Kit Cover 763995-BS 763995-BS 763995-CRM 763995-CRM 763995-WW 763995-WW 763995-ORB 763995-ORB
8 52” Blade Assembly — 763996-BS — 763996-BS — 763996-WW — 763996-ORB
9 44” Blade Assembly 763998-BS — 763998-BS — 763998-WW — 763998-ORB —
10 Harness, Wiring - Reverse
Modular & Aux. Capacitor 764007 764007 764007 764007 764007 764007 764007 764007
11 Handheld Transmitter 763979 763979 763979 763979 763979 763979 763979 763979
12 Electronic Receiver with
Wire Connectors 764009 764009 764009 764009 764009 764009 764009 764009
* Parts Bag, Containing: 764008 764008 764008 764008 764008 764008 764008 764008
13 Connector, Wire, 12 Ga. (3) — — — — — — — —
14 Screw, Pan Head, Ceiling
Cover, M5 x 10mm (1) — — — — — — — —
15 Screw, Flange Head, Blade
M5 x 16mm (10) — — — — — — — —
16 Screw, Serrated Head, Lower
Housing/Light Kit,
M4 x 10mm (1) — — — — — — — —
17 Kit, Balancing — — — — — — — —
18 190W Circuit Breaker 763748 763748 763748 763748 763748 763748 763748 763748
— Owner's Manual BP7407-1 BP7407-1 BP7407-1 BP7407-1 BP7407-1 BP7407-1 BP7407-1 BP7407-1
Repair Parts Listing
