i2F
Digital input 2 configuration: (nu; dor; dEF; AUS; ES; EAL; bAL; PAL; FAn; HdF; onF; LiG; CC;
EMt)
• nu = not used
• dor = door switch function
• dEF = defrost activation
• AUS = auxiliary output
• ES = energy saving mode activation
• EAL = external warning alarm
• bAL = external lock alarm
• PAL = external pressure alarm
• FAn = evaporator fan control
• HdF = holiday defrost
• onF = ON/OFF status change
• LiG = light output control
• CC = change configuration (between C1 and C2)
• EMt = Motion detector
d2d
Digital inputs 2 alarm delay (base time depends on par. ibt): (0 to 255) delay between the
detection of an external event and the activation of the relative function.
nPS
Number of external pressure switch alarms before stopping the regulation: (0 to 15) after
reaching nPS events in the digital input alarm delay (par. dxd), the regulation will be stopped and a
manual restart (ON/OFF, power OFF and power ON) will be required
odC
Compressor and fan status after door opening: (no; FAn; CPr; F-C): no = normal;
FAn = Fans OFF; CPr = Compressor OFF; F-C = Compressor and fans OFF.
rrd
Regulation restart after door alarm: (n; Y) n = no regulation if the door is open; Y = when the rrd
timer elapses, the regulation restarts even if a door open alarm is ON.
5.1.10 Energy saving configuration parameters - ES
ErA
Energy saving algorithm: (nu; bAS) nu=disabled, the energy saving mode activation is by button,
real time clock or digital input; bAS=basic algorithm, the energy saving mode activation depends
on the the digital input.
HES
Energy saving mode temperature differential: (-30.0 to 30.0°C; -54 to 54°F) sets the increasing
value of the set point during the Energy Saving cycle.
LdE
Energy saving controls the lights (lights OFF when energy saving is active): (n; Y) lights off
when energy saving mode is active
StE
Period to switch from normal mode to energy saving mode: (0.0 to 24h00min, res. 10 min) if
the door stay closed for StE time, the energy saving mode will be activated. NOTE: this will require
a door switch to work.
EtS
Period to switch from energy saving mode to normal mode: (0.0 to 24h00min, res. 10 min)
maximum time for energy saving mode. NOTE: this will require a door switch to work.
dS
Door opening time to switch from EtS to StE: (0 to 999 sec) the energy saving mode will be
immediately deactivated as soon as the door stays open more than the dS time. NOTE: this will
require a door switch to work.
5.1.11 Counters, read only values - Cnt
n1H
Number of activations for relay output oA1 (thousands of)
n1L
Number of activations for relay output oA1 (units of)
n2H
Number of activations for relay output oA2 (thousands of)
n2L
Number of activations for relay output oA2 (units of)
n3H
Number of activations for relay output oA3 (thousands of)
n3L
Number of activations for relay output oA3 (units of)
n4H
Number of activations for relay output oA4 (thousands of)
n4L
Number of activations for relay output oA4 (units of)
n5H
Number of total activation of digital input 1 (thousand of)
n5L
Number of total activation of digital input 1 (units of)
n6H
Number of total activation of digital input 2 (thousand of)
n6L
Number of total activation of digital input 2 (units of)
F1H
Number of working hours for relay output oA1 (thousands of)
F1L
Number of working hours for relay output oA1 (units of)
F2H
Number of working hours for relay output oA2 (thousands of)
