Emerson Dixell XR70T Installing And Operating Instructions

1592040000 XR70T EN v1.1 2019.07.09 XR70T 25/40
Prb
P4P
Probe P4 presence
no
Pr1
n(0); Y(1)
Prb
o4
Probe P4 calibration
0
Pr1
°F
[-12.0°C to 12.0°C]
[-21.6°F to 21.6°F]
diS
CF
Temperature measurement unit:
Celsius; Fahrenheit
°F
Pr1
°C(0); °F(1)
diS
rES
Temperature resolution: decimal,
integer
dE
Pr1
dE(0); in(1)
diS
Lod
Probe default displayed
P1
Pr1
P1(0); P2(1); P3(2);
P4(3); SEt(4); dtr(5)
diS
rEd
Remote probe displayed (for XH-REP)
P2
Pr1
P1(0); P2(1); P3(2);
P4(3); SEt(4); dtr(5)
diS
dLy
Temperature display delay (resolution
10 sec)
00:00
Pr1
mm:s
s
0.0 to 20min00sec
diS
dtr
Probe visualization
percentage=F(P1;P2) (dtr=1 means
VALUE=0.01*P1+0.99*P2)
99
Pr1
1 to 99
dEF
EdF
Defrost mode
rtC
Pr2
rtC(0); in(1)
dEF
tdF
Defrost type: electric heating, hot gas
EL
Pr2
EL(0); in(1)
dEF
dFP
Probe selection for defrost control
P2
Pr2
nP(0); P1(1); P2(2); P3(3); P4(4)
dEF
dtE
End defrost temperature
48.0
Pr2
°F
[-50.0°C to 50.0°C]
[-58.0°F to 122.0°F]
dEF
idF
Interval between two successive defrost
cycles
24
Pr2
ora
0 to 255 hours
dEF
MdF
Maximum length of defrost cycle
20
Pr2
min
0 to 255 min
dEF
dSd
Start defrost delay
0
Pr2
sec
0 to 255 sec
dEF
StC
Compressor stop before starting any
defrost
0
Pr2
sec
0 to 255 sec
dEF
dFd
Displaying during defrost
dEF
Pr2
rt(0); it(1); SEt(2); dEF(3);
Coo(4)
dEF
dAd
Temperature display delay after any
defrost cycle
0
Pr2
min
0 to 255 min
dEF
Fdt
Draining time
1
Pr2
min
0 to 255 min
dEF
Hon
Drain heater enabled after draining time
(par. Fdt)
2
Pr2
min
0 to 255 min
dEF
dPo
Defrost cycle enebled at stat-up
no
Pr2
n(0); Y(1)
dEF
od1
Automatic defrost (at the beginning of
any energy saving mode)
no
Pr2
n(0); Y(1)
FAn
FAP
Probe selection for evaporator fan
P2
Pr2
nP(0); P1(1); P2(2); P3(3); P4(4)
FAn
FSt
Evaporator fan stop temperature
50.0
Pr2
°F
[-50.0°C to 50.0°C]
[-58.0°F to 122.0°F]
FAn
HYF
Evaporator fan regulator differential
4.0
Pr2
°F
[0.1°C to 25.0 °C]
[0.1°F to 45.0°F]
FAn
FnC
Evaporator fan operating mode
C-n
Pr2
C-n(0); O-n(1); C-Y(2); O-Y(3)
FAn
Fnd
Evaporator fan delay after defrost cycle
1
Pr2
min
0 to 255 min
FAn
FCt
Differential temperature for cyclic
activation of evaporator fans
(o=disabled)
0
Pr2
°F
[0°C to 50°C]
[0°F to 90°F]
FAn
FSU
Evaporator fan operating mode
Std
Pr2
Std(0); FoF(1); Fon(2)
FAn
Ft
Evaporator fan controlled during defrost
no
Pr2
n(0); Y(1)
FAn
Fon
Evaporator fan ON time in normal mode
(with compressor OFF)
5
Pr2
min
0 to 255 min
FAn
FoF
Evaporator fan OFF time in normal
mode (with compressor OFF)
10
Pr2
min
0 to 255 min
FAn
Fo1
Evaporator fan ON time in energy
saving mode (with compressor OFF)
5
Pr2
min
0 to 255 min
FAn
FF1
Evaporator fan OFF time in energy
saving mode (with compressor OFF)
10
Pr2
min
0 to 255 min
FAn
Fd1
Evaporator fan delay
0
Pr2
sec
0 to 255 sec
