19 Default Setting Values
Label Name Range Value Level
SEt Setpoint LS to US
[-5.0°C]
[23°F]
- - -
HY Differential
[0.1 to 25.5°C]
[1 to 255°F]
[2.0°C]
[2°F]
Pr1
LS Minimum setpoint
[-50°C to SET]
[-58°F to SET]
[-50.0°C]
[-58°F]
Pr2
US Maximum setpoint
[SET to 110°C]
[SET to 230°F]
[110.0°C]
[230°F]
Pr2
ot Thermostat probe calibration
[-12 to 12°C]
[-21 to 21°F]
[0.0°C]
[0°F]
Pr1
P2P Evaporator probe presence n=not present; Y=pres. Y Pr1
oE Evaporator probe calibration
[-12 to 12°C]
[-21 to 21°F]
[0.0°C]
[0°F]
Pr2
P3P Third probe presence n=not present; Y=pres. n Pr2
o3 Third probe calibration
[-12.0 to 12.0°C]
[-21 to 21°F]
[0.0°C]
[0°F]
Pr2
P4P Fourth probe presence n=not present; Y=pres. n Pr2
o4 Fourth probe calibration
[-12.0 to 12.0°C]
[-21 to 21°F]
[0.0°C]
[0°F]
Pr2
odS Outputs delay at start up 0 to 255 min 0 Pr2
AC Anti-short cycle delay 0 to 50 min 1 Pr1
rtr P1-P2 percentage for regulation 0 to 100 (100=P1, 0=P2) 100 Pr2
CCt Continuous cycle duration 0.0 to 24h 00min, res. 10min 0.0 Pr2
CCS Setpoint for continuous cycle
[-50 to 110.0°C]
[-58 to 230°F]
[-5°C]
[23°F]
Pr2
Con
Compressor ON time with faulty
probe
0 to 255 min 15 Pr2
CoF
Compressor OFF time with faulty
probe
0 to 255 min 30 Pr2
CF Temperature measurement unit °C; °F [°C] [°F] Pr2
rES Resolution in=integer; dE= dec.point dE Pr1
Lod Probe displayed P1; P2 P1 Pr2
rEd
2
X-REP display P1; P2; P3; P4; SEt; dtr P1 Pr2
dLY Display temperature delay 0.0 to 20min 00s, res. 10s 0.0 Pr2
dtr P1-P2 percentage for display 1 to 99 50 Pr2
tdF Defrost type EL=el. heater; in= hot gas EL Pr1
dFP
Probe selection for defrost
termination
nP; P1; P2; P3; P4 P2 Pr2
Table 19-1- XR75CX Default Setting Values (
2
Only for XR75CX with X-REP output)
