28 • XR75CX I&O Manual 026-1210 Rev 4
AU2 Condenser for high temperat. alarm
[-50 to 110°C]
[-58 to 230°F]
[110°C]
[230°F]
Pr2
AH2
Differential for condenser
temperature alarm recovery
[0.1°C to 25.5°C]
[1°F to 45°F]
[5°C]
[5°F]
Pr2
Ad2 Condenser temperature alarm delay 0 to 254 min, 255=nU 15 Pr2
dA2
Delay of cond. temper. alarm at start
up
0.0 to 24h 00min, res. 10min 1.3 Pr2
bLL
Compr. off for condenser low
temperature alarm
n; Y n Pr2
AC2
Compressor off because of condenser
high temperature alarm
n; Y n Pr2
tbA Alarm relay disabling n; Y Y Pr2
oA2 Second relay configuration
ALr = alarm;
dEF = do not select it;
LiG =Light;
AUS =AUX;
onF=always on;
FAn= do not select it;
db = neutral zone;
CP2 = second compressor;
dF2 = do not select it;
HES = night blind
LiG Pr2
AoP Alarm relay polarity (oA2=ALr) oP; CL CL Pr2
i1P Digital input polarity (18-20) oP=opening; CL=closing CL Pr1
i1F Digital input 1 configuration (18-20) dor; dEF; dor Pr1
i2P Digital input polarity (18-19) oP=opening; CL=closing CL Pr2
i2F Digital input configuration (18-19)
EAL; bAL; PAL; dor; dEF; ES;
AUS; Htr; FAn; HdF; onF
EAL Pr2
did Digital input alarm delay (18-20) 0 to 255 min 15 Pr1
doA Door open alarm delay 0 to 255 min 15 Pr1
NPS
Number of activation of pressure
switch
0 to 15 15 Pr2
odC
Compress and fan status when door
open
no; FAn; CPr; F_C F-C Pr2
rrd
Regulation restart with door open
alarm
n; Y Y Pr2
HES Differential for Energy Saving
[-30°C to 30°C]
[-54°F to 54°F]
0 Pr2
Adr Serial address 1 to 247 1 Pr2
PbC
Kind of probe (set to CtC for standard
CPC temp sensors - factory default)
ntC; CtC ntC Pr2
onF on/off key enabling nU, oFF; ES nU Pr2
dP1 Room probe display -- - Pr1
dP2 Evaporator probe display -- - Pr1
Label Name Range Value Level
Table 19-1- XR75CX Default Setting Values (
2
Only for XR75CX with X-REP output)
