Service Instructions
074985 Rev. B
October 2014
8
Section 7: Housing Group Disassembly
Housing Group Disassembly
Section 7: Housing Group Disassembly
1. Remove cover screw (1-30) and gasket seals (6-80).
2. Remove housing cover (1-20).
NOTE:
Housing cover has a tight fit and will require the use of two pry bars or screw drivers to
assist in removal.
3. Move the yoke arms to the center position.
4. Remove upper yoke roller (1-50).
5. Remove yoke pin (1-40).
6. Holding rod bushing (2-40) in place, remove piston rod (2-10).
7. Remove both rod bushings (2-40) from housing (1-10).
8. Remove yoke (1-140) from housing (1-10).
9. Remove lower yoke roller (1-50).
10. Remove stop screws (1-60), jam nuts (1-70), and gasket seals (6-90).
Be sure to identify the stop screws.
11. It is not necessary to remove housing pipe plug (1-100) or cylinder adapter
pipe plug (2-110).
