WAVEFORMS
1-11-1
H9600WF
WF 1
WF3
WF1
V-OUT E-E
10µs 50mV x 10
UPPER
WF2
WF2
LOWER
V-OUT 0.1V x 10
RF-SW 0.5V x 10
50µs
C-PB 10mV x 10
RF-SW 0.5V x 10
5ms
TP751
TP751
TP302
UPPER
LOWER
TP302
TP301
WF4
WF6 Pin 14 of IC1402
WF5
VIDEO-Y
VIDEO-Y
0.2V
0.2V
20
20
µs
VIDEO-C
VIDEO-C
0.2V
0.2V
20
20
µs
VIDEO-CVBS
VIDEO-CVBS
0.5V
0.5V
20
20
µs
s
WF7
AUDIO-L
AUDIO-L
1V
1V
0.5ms
0.5ms
WF8
AUDIO-R
AUDIO-R
1V
1V
WF9
SPDIF
SPDIF
1V
1V
0.1
0.1
µs
s
Pin 8 of CN1601
Pin 10 of CN1601
Pin 14 of CN1601
Pin 16 of CN1601
Pin 19 of CN1601
NOTE:
Input
VCR: COLOR BAR SIGNAL (WITH 1KHz AUDIO SIGNAL)
(WF1~WF3, WF10, WF11, WF14, WF15)
DVD: POWER ON (STOP) MODE
(WF4~WF6)
CD: 1kHz PLAY
(WF7~WF9)
0.5ms
0.5ms
