Emerson EWD7002 Service Manual

1-5-1 E5662IB
OPEN/CLOSE PLAY
SKIP
SEARCH
PAU SE
STOP
POWER
CD
12 11 2 44
8
73 51
FRONT PANEL
REMOTE CONTROL
RETURNZOOM
MODE
MENU
SKIPPAU S EA-B
REPEAT
ANGLE
AUDIO
SUB
TITLE
CLEAR
TITLE
STOP
PLAY
FWDREV
SETUP
ENTER
OPEN/
CLOSE
SEARCH
MODE
DISPLAY
123
456
789
0 +10
POWER
13
5
14
15
16
17
18
19
3
20
2
30
21
22
23
26
27
25
24
28
4
10
9
29
11
6
1. Display, Remote Sensor Window
2. PLAY Button
Starts playback of the disc contents.
3. PAUSE Button
Pauses the current disc operation.
4. STOP Button
Stops operation of the disc.
5. POWER Button
Press to turn the power on and off.
6. SEARCH MODE Button
Press to locate a desired point.
7. SKIP UP/FWD Button (main unit)
Plays back from the beginning of the next chapter or
track. Hold down to fast forward playback.
8. SKIP DOWN/REV Button (main unit)
Plays back from the beginning of the current chapter
or track. Hold down to fast reverse playback.
9. SKIP UP Button (remote control)
Plays back from the beginning of the chapter or track.
10. SKIP DOWN Button (remote control)
Plays back from the beginning of the current chapter
or track.
11. OPEN/CLOSE Button
Press to insert discs into or remove them from the tray.
12. Disc loading tray
13. DISPLAY Button
Displays the current status on the TV screen for
checking purposes.
14. AUDIO Button
Press to select a desired audio language or sound mode.
15. SUBTITLE Button
Press to select a desired subtitle language.
16. ANGLE Button
Press to change the camera angle to see the sequence
being played back from a different angle.
17. REPEAT Button
Repeats playback of the current disc, title, chapter or
track.
18. A-B REPEAT Button
Repeats playback of a selected section.
19. CLEAR Button
Resets a setting.
20. REV Button
Fast reverse playback to a desired point.
21. SETUP Button
Press to enter the setup mode or to change setup items.
22. MODE Button
Activates program playback or random playback mode
when playing CDs or MP3. Sets Black level or SRS
TruSurround.
23. TITLE Button Displays the title menu.
24. ENTER Button Press to accept a setting.
25. RETURN Button
Returns to the previous operation.
26. Arrow Buttons
Use when making settings while watching the
display on a TV screen.
27.
MENU Button Displays the disc menus.
28. FWD Button
Fast forwards playback to a desired point.
29. Numeric Buttons
30. ZOOM Button
Enlar
ges part of a DVD-reproduced image.
OPERATING CONTROLS AND FUNCTIONS

Emerson EWD7002 Specifications

General

Brand	Emerson
Model	EWD7002
Category	DVD Player
Language	English
